LDM060-1205-C21
60W Class 2 Constant Voltage LED Driver
With 5 Year Warranty
105675
The LDM060 is a 60W, Class 2 Power Supply, which can be used in outdoot and UL listed dry, wet and damp locations.
It operates from 90-305V input voltage. It is designed and manufactured for LED Signage Modules, LED Strips, or Outdoor Constant Voltage operated LED based products.
The high efficiency of these drivers and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, output over voltage, over current short circuit and over temperature.
Waterproof (IP 68) and UL Dry / Damp / Wet Locations
Class 2 Power Supply
High Efficiency up to 88%
Constant Voltage Output
Input Surge Protection 2KV Line to Line and 4KV Line to Earth
All-Around Protection: OVP / OCP / SCP / OTP
5 Years Product Warranty
